16.7 MULTIFUNCTION INPUT MONITOR C
000.0 °C
000 %
On
Multifunction
Input
Power Request
— Multifunction input enabled for cooling capacity request
— Input value in the size selected
— Value of the cooling capacity requested as a percentage
16.8 MULTIFUNCTION INPUT MONITOR D
000.0 °C
07.0 °C
45.0 °C
On
Multifunction
Input
Cooling Comp.
Heating Comp.
— Multifunction input enabled for setpoint compensation
— Input value in the size selected
— Compensation to add to/deduct from the cooling set in °C
— Compensation to add to/deduct from the heating set in °C
17 CLOCK MENU
This menu is used to view and modify the following parameters:
— Time
— Date
— Day of the week
— Programmer timer and time bands for every day of the week
17.1 TIME, DATE AND DAY DISPLAY MONITOR
08:42
16/09/21
FRIDAY
Clock cong.
Time
Date
Day
This mask is used to display and modify the time, date and day of the week param-
eters.
17.2 TIMER ENABLING MONITOR
N
Enable weekly
time zones
This mask is used to enable the weekly time band timer (Y = enabled, N = disabled).
17.3 TIME ZONE 1 CHANGE MONITOR
00:00 00:00
FRIDAY
Start Stop
Day Zone 1
This mask is used to modify the day of the week and the times of zone 1 (see the
Zone diagram).
17.4 TIME ZONE 2 CHANGE MONITOR
00:00 00:00
FRIDAY
Start Stop
Day Zone 2
This mask is used to modify the times of zone 2 (see the Zone diagram).
17.5 OPERATING ZONE DIAGRAM
If enabled, the weekly time band timer is used to set 2 operating zones for each day
of the week (if one zone has the same start and stop time, it is disabled).
The diagram below shows an example of two operating zones:
00:00
23:59
ON ON
Stop 2Stop 1 Start 2Start 1
TIMEZONE 2TIMEZONE 1
