AERMEC PGD1 User Manual

37
18.26 MULTIFUNCTION INPUT WITH EXTERNAL POWER
REQUEST MONITOR
0 %
100 %
Probe 7 cong.
Demand Low
Demand High
External Demand
— Multifunction input enabled with external power request function (MASTER
ONLY )
— Power request corresponding to the minimum size of the input
— Power request corresponding to the maximum size of the input
18.27 MULTIFUNCTION INPUT WITH SETPOINT
COMPENSATION MONITOR A
07.0 °C
12.0 °C
Probe 7 cong.
Comp. Low
Comp. High
Ext. Cooling Comp.
— Multifunction input enabled with setpoint compensation with temperature
probe function (MASTER ONLY)
— Cooling set compensation corresponding to the minimum size of the input
— Cooling set compensation corresponding to the maximum size of the input
18.28 MULTIFUNCTION INPUT WITH SETPOINT
COMPENSATION MONITOR B
45.0 °C
50.0 °C
Probe 7 cong.
Comp. Low
Comp. High
Ext. Heating Comp.
— Multifunction input enabled with setpoint compensation with temperature
probe function (MASTER ONLY)
— Heating set compensation corresponding to the minimum size of the input
— Heating set compensation corresponding to the maximum size of the input
18.29 DIGITAL CONTACT ENABLING MONITOR
N
Enable Digital
Demand
Power request enabling from digital contacts ID 16, ID 17, ID 18 (MASTER ONLY).
18.30 DIGITAL CONTACT SETTING MONITOR
040 %
075 %
100 %
Digital Demand Step
Step1
Step2
Step3
Digital contact power step setting (MASTER ONLY):
— Power step 1 ID 16
— Power step 2 ID 17
— Power step 3 ID 18
18.31 PULL DOWN CONTROL ENABLING MONITOR
N
0.1 °C/m
0180 s
Pull Down
Temp. Rate
Delay Comp.
Pull Down control enabling (MASTER ONLY):
— Water temperature variation rate below which the activation of new steps is
enabled
— Delay time between the activation of two subsequent steps
