MAINTENANCE MANUAL
IFR 6000
2-2-3
Page 32
Aug 1/06
STEP PROCEDURE
21. Connect ARB #1 to the computer USB port and using the Intuilink software, send
the file “JIT_1r0.wvf”, found on the IFR 6000 maintenance manual CD, to ARB
#1 volatile memory. Enter the required Frequency and Output voltage from
table 18.3 when prompted.
22. Verify ARB #1 Generator is set as:
Function ARB #1
Frequency .222222kHz
Output Pulse, 4Vpp, 2V Offset
Trigger External, positive slope
Mode Burst, 1 cycle
Impedance High Z
23. Verify the reply delay jitter value on the UUT is .82µS ±.02µS.
24. Press the STOP TEST Soft key.
25. Disconnect the coax from the UUT ANT connector and connect it to Ch.2 on the
frequency counter.
26. Set the RF Generator for CW output and measure the frequency of the RF
Generator at 1087, 1090, and 1093MHz.
27. Disconnect the coax from Ch.2 of the frequency counter and reconnect it to the
UUT ANT connector.
28. Set the RF Generator for external pulse modulation.
29. Press the NEXT TEST Soft Key on the UUT to display the XPDR-POWER/FREQ
screen.
30. Press the RUN TEST Soft key.
31. Verify that the UUT displays the measured RF Generator frequency ±50kHz at
1087, 1090, and 1093MHz.
32. Press the STOP TEST Soft key.
