17
4451C EN 2013-04-30 Introducing the CR 85-X
CR 85-X DIGITIZER
• You can hurt your fingers if they are caught between the CR cassette and
the edge of the input slot. Insert the cassette in the input buffer as
described in ‘Reading an image plate’ on page 38. At all times, keep your
fingers clear of the input slot. As soon as the CR 85-X takes in the cassette,
release it.
Safety instructions for laser products
The digitizer is a Class 1 Laser Product. It uses one laser diode of a 80 mW
type, classification class IIIb, wavelength 640-670 nm. The laser beam’s
deflection frequency is 120 1/s up to 170 1/s. The laser beam divergence is
12 mrad.
Under normal operating conditions - when both doors are closed - there can
be no laser radiation outside the CR 85-X. It is nonetheless imperative that the
local radiation safety regulations regarding the protection of staff against
scattered radiation are complied with, if the CR 85-X is located in the
immediate vicinity of an X-ray room.
Open the front left and right door only to solve cassette or image plate jams.
When you open either of the doors, the power supply of all critical
components is switched off automatically as a precaution.
