Operation 2
3200P pH Meter User Guide 13
Figure 5 Front view of the pH 3200P Meter
Figure 6 Back view of the pH 3200P Meter
Display
Keypad
Ground
Reference electrode socket
pH Combination electrode socket
ATC probe socket
USB
Power (DC 9V 800 mA)
