Agilent Technologies 34401A - Basic Measurement Procedures

To Measure Voltage
Ranges: 100 mV, 1 V, 10 V, 100 V, 1000 V (750 Vac)
Maximum resolution: 100 nV (on 100 mV range)
AC technique: true
RMS, ac-coupled
To Measure Resistance
Ranges: 100 Ω, 1 kΩ, 10 kΩ, 100 kΩ, 1 MΩ, 10 MΩ, 100 MΩ
Maximum resolution: 100 µΩ (on 100 ohm range)
1
Chapter 1 Quick Start
To Measure Voltage
17
