A Front-Panel Menu Tutorial
This section is a step-by-step tutorial which shows how to use the
front-panel menu. We recommend that you spend a few minutes with this
tutorial to get comfortable with the structure and operation of the menu.
The menu is organized in a top-down tree structure with three
levels (menus, commands, and parameters). You move down
∨
or up
∧ the menu tree to get from one level to the next. Each of the
three levels has several horizontal choices which you can view by
moving left
< or right > .
• To turn on the menu, press Shift Menu On/Off .
• To turn off the menu, press Shift Menu On/Off , or press any of
the function or math keys on the top row of front-panel keys.
• To execute a menu command, press Enter .
• To recall the last menu command that was executed,
press
Shift Recall .
Menus
Parameters
Commands
2
Chapter 2 Front-Panel Menu Operation
A Front-Panel Menu Tutorial
29
