Agilent Technologies 34401A User Manual

Understanding the “ % of range ” Error The range error compensates
for inaccuracies that result from the function and range you select.
The range error contributes a constant error, expressed as a percent of
range, independent of the input signal level. The following table shows
the range error applied to the multimeter’s 24-hour dc voltage specification.
Total Measurement Error To compute the total measurement error,
add the reading error and range error. You can then convert the total
measurement error to a “percent of input” error or a “ppm (part-per-
million) of input” error as shown below.
% of input error =
Total Measurement Error
Input Signal Level
× 100
ppm of input error =
Total Measurement Error
Input Signal Level
× 1,000,000
Error Example Assume that a 5 Vdc signal is input to the multimeter on the 10 Vdc range.
Compute the total measurement error using the 90-day accuracy
specifications:
± (0.0020% of reading + 0.0005% of range).
Range
10 Vdc
10 Vdc
10 Vdc
Input Level
10 Vdc
1 Vdc
0.1 Vdc
Range Error
(% of range)
0.0004
0.0004
0.0004
Range
Error Voltage
≤ 40 µV
≤ 40 µV
≤ 40 µV
Reading Error
Range Error
Total Error
= 0.0020%
× 5 Vdc
= 0.0005%
× 10 Vdc
= 100
µV + 50 µV
= 100 µV
= 50
µV
=
± 150 µV
= ± 0.0030% of 5 Vdc
=
± 30 ppm of 5 Vdc
8
Chapter 8 Specifications
To Calculate Total Measurement Error
225
