Menu Example 1 The following steps show you how to turn on the menu, move up or
down between levels, move across the choices on each level, and turn off
the menu. In this example, you will turn off the front-panel beeper.
1 Turn on the menu.
You enter the menu on the “menus” level. The
MEAS MENU is your first
choice on this level.
A: MEAS MENU
2 Move across to the
SYS MENU choice on this level.
There are six menu group choices available on the “menus” level. Each
choice has a letter prefix for easy identification (
A: , B: , etc.).
D: SYS MENU
3 Move down to the “commands” level within the
SYS MENU.
The
RDGS STORE command is your first choice on this level.
1: RDGS STORE
∨
> >
>
Shift <
On/Off
2
Chapter 2 Front-Panel Menu Operation
A Front-Panel Menu Tutorial
31
