Spurious Signals (continued)
Measurement Lower
Limit
Upper Limit
(dBfs)
Measured Value
(dBfs)
Pass/Fail
Two Ch, 38400 Hz Start, Ch 2 -80
Two Ch, 40000 Hz Start, Ch 1 -80
Two Ch, 40000 Hz Start, Ch 2 -80
Two Ch, 41600 Hz Start, Ch 1 -80
Two Ch, 41600 Hz Start, Ch 2 -80
Two Ch, 43200 Hz Start, Ch 1 -80
Two Ch, 43200 Hz Start, Ch 2 -80
Two Ch, 44800 Hz Start, Ch 1 -80
Two Ch, 44800 Hz Start, Ch 2 -80
Two Ch, 46400 Hz Start, Ch 1 -80
Two Ch, 46400 Hz Start, Ch 2 -80
Two Ch, 48000 Hz Start, Ch 1 -80
Two Ch, 48000 Hz Start, Ch 2 -80
Two Ch, 49600 Hz Start, Ch 1 -80
Two Ch, 49600 Hz Start, Ch 2 -80
Amplitude Accuracy
Measurement Lower
Limit
(dBVrms)
Upper Limit
(dBVrms)
Measured Value
(dBVrms)
Pass/Fail
-51 dBVrms, Ch 1 -51.15 -50.85
-51 dBVrms, Ch 2 -51.15 -50.85
-51 dBVrms, Ch 3 -51.15 -50.85
-51 dBVrms, Ch 4 -51.15 -50.85
-43 dBVrms, Ch 1 -43.15 -42.85
-43 dBVrms, Ch 2 -43.15 -42.85
-43 dBVrms, Ch 3 -43.15 -42.85
-43 dBVrms, Ch 4 -43.15 -42.85
-35 dBVrms, Ch 1 -35.15 -34.85
