Agilent 35670A Specifications
General Specifications
1-13
General Specifications
Safety Standards IEC61010-1:2001/EN61010-1:2001 (2nd Edition)
Canada: CAN/CSA-C22.2 No. 61010.1-2004
USA: ANSI/UL 61010-1:2004
EMC Standards Canada: ICES-001:2004
IEC 61326-1:2005/EN61326-1:2006
Australia/New Zealand: AS/NZS CISPR11:2004
Acoustics LpA <55 dB (cooling fan at high speed setting)
LpA <45 dB (auto speed setting at 25 °C)
Fan speed setting of high, automatic, and off are available. The fan off setting can be
enabled for a short period of time, except at higher ambient temperatures where the fan
will stay on.
Environmental
Operating Restrictions
Operating:
Disk in Drive
Operating:
No Disk in Drive
Storage and
Transport
Ambient Temperature 4 °C to 45 °C 0 °C to 55 °C –40 °C to 70 °C
Relative Humidity (non-condensing)
Minimum 20% 15% 5%
Maximum 80% at 32 °C 95% at 40 °C 95% at 50 °C
Vibration (5 – 500 Hz) 0.6 Grms 2.1 Grms 3.41 Grms
Shock 5 G
(10 ms 1/2 sine)
5 G
(10 ms 1/2 sine)
40 G
(3 ms 1/2 sine)
Maximum Altitude 4600 meters (15,000 feet)
AC Power 100 Vrms to 240 Vrms (47 Hz to 440 Hz)
350 VA maximum
DC Power 12 Vdc to 28 Vdc nominal
200 VA maximum
DC Current at 12V (typical) 10 A (standard)
12 A (4 Channel, Option AY6)
Warm-Up Time 15 minutes
Weight 15 kg (33 lbs) net
29 kg (64 lbs) shipping
Dimensions
(excluding bail handle and
impact cover)
Height: 190 mm (7.5 in)
Width: 340 mm (13.4 in)
Depth: 465 mm (18.3 in)
IEC 801-3 (Radiated Immunity): Performance degradation may occur at Security Level 2.
