To install the analyzer
The analyzer is shipped with rubber feet and bail handle in place, ready for use as a
portable or bench analyzer.
• Install the analyzer to allow free circulation of cooling air.
Cooling air enters the analyzer through the right side and exhausts through the left side
and rear panel.
• To install the analyzer in an equipment cabinet, follow the instructions shipped with
the rack mount kit.
Warning To prevent potential fire or shock hazard, do not expose the analyzer to rain or
other excessive moisture.
• Protect the analyzer from moisture and temperatures or temperature changes that cause
condensation within the analyzer.
The operating environment specifications for the analyzer are listed in chapter 1,
‘’Specifications.’’
• Protect the analyzer’s disk drive from dirt and dust.
Remove the screw to the right of the disk drive and use it to attach the supplied disk
drive cover. The disk drive cover is located inside the front-panel impact cover.
Caution Use of the equipment in an environment containing dirt, dust, or corrosive substances
will drastically reduce the life of the disk drive and the flexible disks. To minimize
damage, use the disk drive cover and store the flexible disks in a dry, static-free
environment.
Agilent 35670A Preparing the Analyzer for Use
To install the analyzer
2-7
