Cross Channel Amplitude
FFT cross channel gain accuracy
Frequency response mode, same amplitude range (AC coupled,periodic chirp,uniform window,>=4Hz)
At full scale: Tested with 10 rms averages
on the -11 to +27 dBvrms ranges, and 100
rms averages on the -51 dBVrms range
±0.04 dB (0.46%)
At -20 dBfs: Tested with 200 rms averages
on the -11 to +27 dBVrms ranges, and 2000
rms averages on the -51 dBVrms range
±0.08 dB (0.92%)
Cross Channel Phase
Cross channel phase accuracy
(same conditions as cross-channel amplitude)
±0.5 degree
Agilent 35670A Specifications
Cross Channel Amplitude
1-7
