Digital Interfaces
External keyboard Compatible with PC-style 101-key keyboard
model number HP C1405A (#ABA) and HP
keyboard cable part number 5081-2249 (DIN
connector).
GPIB Conforms to the following standards:
IEEE 488.1 (SH1, AH1, T6, TEO, L4, LE0,
RS1, RL1, PP0, DC1, DT1, C1, C2, C3, C12,
E2)
IEEE 488.2-1987
Complies with SCPI 1992
Factory set address: 11
Data transfer rate
(REAL 64 Format)
<45 ms for a 401 point trace
Serial port (printing, plotting) 300 baud to 9600 baud
Parallel port (printing, plotting)
Specifications Agilent 35670A
Digital Interfaces
1-12
