Agilent Technologies 35670A Installation Guide

Measurement Uncertainty
The following table lists the measurement uncertainty and ratio for each performance
test using the recommended test equipment. Except for the External Trigger test, the
ratios listed for the recommended test equipment meet or exceed the measurement
uncertainty ratio required by U.S. MIL-STD-45662A.
• If you are using equipment other than the recommended test equipment, you may
calculate and record the measurement uncertainty and ratio for each performance test.
The table may be reproduced without written permission of Agilent.
Performance Test Using Recommended Test Equipment Using Other Test Equipment
Measurement Uncertainty Ratio Measurement Uncertainty Ratio
Self Test NA NA NA NA
DC Offset NA NA NA NA
Noise NA NA NA NA
Spurious Signals NA NA NA NA
Amplitude Accuracy
-51 dBVrms
-43 dBVrms
-35 dBVrms
-27 dBVrms
-11 dBVrms
1 dBVrms
9 dBVrms
19 dBVrms
27 dBVrms
±0.020 dB
±0.0084 dB
±0.004 dB
±0.003 dB
±0.001 dB
±0.0008 dB
±0.001 dB
±0.00081 dB
±0.00117 dB
7.7:1
>10:1
>10:1
>10:1
>10:1
>10:1
>10:1
>10:1
>10:1
Flatness
25.6 kHz, 27 dBVrms
25.6 kHz, 9 dBVrms
25.6 kHz, -11 dBVrms
51.2 kHz, 27 dBVrms
51.2 kHz, 9 dBVrms
51.2 kHz, -11 dBVrms
99.84 kHz, 27 dBVrms
99.84 kHz, 9 dBVrms
99.84 kHz, -11 dBVrms
±0.01487 dB
±0.01277 dB
±0.01277 dB
±0.02025 dB
±0.01460 dB
±0.01583 dB
±0.02025 dB
±0.01460 dB
±0.01583 dB
>10:1
>10:1
>10:1
10:1
>10:1
>10:1
10:1
>10:1
>10:1
NA (not applicable) internal test
Verifying Specifications Agilent 35670A
Measurement Uncertainty
3-54
