Agilent Technologies 4072A Advanced

Chapter 2 17
Agilent 4072/4073 Preinstallation Guide, Edition 4
Site Preparation
Installation Site Requirements
Figure 2-5 Testhead layout
642 mm
890 mm - 1010 mm
( The hight is from floor to DUT )
testhead
DUT
17" flat panel
display
Rear view
switch board
testhead
table
keyboard
table
17" flat panel
display
system
cabinet
system
cabinet
600 mm
