62 Chapter 4
Agilent 4072/4073 Preinstallation Guide, Edition 4
Receiving
Unpacking System Cabinet
Unpacking System Cabinet
The customer is responsible for unpacking the Agilent 4072/4073 tester system cabinet and moving it to the final
location in the clean room.
This section covers how to unpack the system cabinet. The system cabinet is stored in the carton, and is removed
from the carton and put down on the floor using the following procedure.
CAUTION At least two persons are required to slide the cabinet down to the floor.
1. Cut the nylon straps securing the box.
2. Remove the top cover.
3. Remove the adhesive tape on the corner to
remove the side cover.
4. Remove the other side cover.
5. Remove the cover on the top.
6. Cut the nylon strap that ties the cabinet and the
slope together.
To Next Page
