76 Appendix A
Agilent 4072/4073 Preinstallation Guide, Edition 4
Confirming the System Power Safety
Component Location for PDU and Checking EMO
Component Location for PDU and Checking EMO
For the location of the components shown in this procedure, see Figure 4-4 through Figure 4-8.
Figure 4-4 System cabinet component locations (rear view)
Figure 4-5 System cabinet component location (front view)
instrument power outlets
controller power outlets
power distribution unit (PDU)
DVM and CMU power outlets
(200/208 V option only)
EMO switch
LINE indicator
INSTRUMENT
POWER ON
INSTRUMENT
POWER OFF
