Agilent 4072/4073 Preinstallation Guide, Edition 4
Site Preparation
Electrical Requirements
Table 2-3 Number of installable unit
Mounted system controller DDS drive rackmount 81110A 8114A E4411B
000
500
410
None 2 2 0
201
111
c8000 0 2 1
(or C3750) 4 0 0
310
Yes 1 2 0
101
011
501
None None 4 1 1
221
Table 2-4 Power consumption of 4072/4073 system instruments
Component
Line voltage
AC 200 V AC 208 V AC 220 V AC 240 V
System cabinet 1.0 A 1.0 A 0.9 A 0.9 A
Testhead power supply (with testhead) 2.5 A 2.4 A 2.3 A 2.1 A
E4980A or 4284A presicion LCR meter 0.8 A 0.8 A 0.7 A 0.7 A
3458A digital multimeter 0.4 A 0.4 A 0.4 A 0.4 A
System controller (HP workstation c8000) 3.9 A 3.8 A 3.6 A 3.3 A
System controller (HP Visualize C3750) 3.5 A 3.4 A 3.2 A 3.0 A
DDS drive 0.6 A 0.6 A 0.6 A 0.5 A
81110A pulse generator (1 ea) 1.5 A 1.5 A 1.4 A 1.3 A
8114A pulse generator (1 ea) 2.5 A 2.4 A 2.3 A 2.1 A
E4411B spectrum analyzer 1.5 A 1.5A 1.4 A 1.3 A
Color display (19 inch) 1.4 A 1.3 A 1.2 A 1.2 A
