6 General Maintenance
190 5977B Series MSD Operating Manual
4 Extractor lens G3870-20444
5 Extractor lens insulator G3870-20445
6 Filaments G7005-60061
7 Spring washer 3050-1301
7 Flat washer 3050-0982
8 Lens insulator G3870-20530
9 Entrance lens assembly, Extended G7000-20026
10 Ion focus lens 05971-20143
11 Repeller insulator G1099-20113
12 Repeller G3870-60171
13 Flat washer 3050-0891
14 Belleville spring washer 3050-1301
15 Repeller nut 0535-0071
16 Source heater block assembly G3870-60177
17 Repeller block insert G3870-20135
Not shown EI XTR source assembly G7003-67720
Table 2 2 Parts list for EI XTR source (Figure 60) (continued)
Item Description Part number
