1b-25
Operation Reference
Function
• MODE determines whether the message will be output once or multiple times when INCR SET
(START/STOP) is pressed.
SINGLE: Outputs the message once.
BURST: Outputs the message the number of times specified in the BURSTS field (3
times in this example).
CONT: Outputs the message continuously until the
INCR SET (START/STOP) key is
pressed a second time.
• AMPLITUDE sets the signal output level of the carrier.
• BURSTS sets the number of times the message will be transmitted. This parameter is displayed
only when the MODE parameter is set to BURST. The allowable range is 1 to 255.
• RF OFF is displayed below the amplitude setting when the RF output is turned off. To toggle the
RF signal output on and off, press
RF ON/OFF.
• HOLD is displayed when the step attenuator is held at its current range setting. To toggle the
attenuator hold function on and off, press
ATTN HOLD.
Entering the Pager Capcode (Address) The pager code menu looks like the following:
• PAGER CODE accepts only numeric characters up to 7 digits.
Use the numeric keys to enter the capcode. Terminate your entry with the
MHz/dB(m) (ENTER)
key.
Message During Encoding To start and stop encoding after selecting all pager encoder
parameters, press the
INCR SET (START/STOP) key. The following display is shown during encoding
a pager under test.
NOTE If the RF output is turned off, AMPLITUDE x.xdBm will be substituted for RF OFF.
While encoding, the blinking cursor is on the first character A of AMPLITUDE or R of
RF OFF.
