1 Installing the GC
Installation and First Startup 11
The 8890 GC
Figure 1. Front of the 8890 GC
Figure 2. Back of the 8890 GC
Inlets
Oven
Detectors
Power switch
Touchscreen
Inlet vents
Electronic
cable
connections
Oven exhaust
vents
EPC cooling
intake
Power
connection
Gas supply
connections
