1 Installing the GC
14 Installation and First Startup
Figure 3. Correct position of the oven exhaust deflector
The oven exhaust deflector accepts a 10-cm (4 in.) diameter exhaust duct, and adds
about 13 cm to the depth of the GC, but this additional depth does not increase the depth
required for proper ventilation.
