How to Use Laser Source Modules Laser Sources
Agilent 8163A/B, 8164A/B & 8166A/B Mainframes, Sixth Edition 111
2 Select <1309.6+1551.6>, using the cursor key, and press Enter. You will see the
screen in Figure 59 .
Figure 59 Dual-Wavelength Laser Source Outputs Both Wavelength
How to Enable/Disable Laser Output
To enable laser output using the user interface:
1 Move to [State] parameter and press Enter.
2 Move to [On], by using the cursor key, and press Enter. The green LED on the
module front panel switches on.
To disable laser output using the user interface:
1 Move to [State] parameter and press Enter.
2 Move to [Off], by using the cursor key, and press Enter. The green LED on the
module front panel switches off.
For further information on modulating the optical output of a dual-
wavelength laser source module, see “How to Modulate Dual-Wavelength
Laser Source Modules” on page 115.
NOTE
