Agilent 8164A Specifications
The Agilent 8164A Lightwave Measurement System displays five
channels.
[1]
Agilent 8163A Series modules are NOT compatible with the 8153A
Lightwave Multimeter.
[2]
For code compatibility to the 8153A Lightwave Multimeter please refer
to the mainframe’s Programming Guide, part number 08164-91016.
Display 600 × 400 pixels visible, active colour LCD.
VGA connector for external monitor.
Compatibility The Agilent 8164A mainframe supports all 8153A Series and
Agilent 8163A Series modules.
[1]
Environmental
Storage temperature
Operating temperature
Humidity
-40° C to 70° C
10° C to 35° C
< 80% R.H. from 10° C to 35°C
Power 100 - 240 V
rms
± 10%, 50 - 60 Hz, 280 VA max.
Dimensions 145 mm × 426 mm × 545 mm
(5.8" × 16.9" × 21.6")
Weight net, 20 kg (45 lb.), 23 kg (51 lb.), including modules.
GPIB interface
Function code
SH1, AH1, T6, L4, SR1, RL1, PP0, DC2, DT0, C0. SCPI standard;
[2]
RS232C Interface: max. baud rate 115200 bps
Parallel Printer Interface Centronics
Number of Modules 4 front-loadable Modules, 1 back-loadable Module
PC-Card slot PCMCIA 2.0/JEIDA 4.0
Data Storage Internal Hard Disk Drive: 3250 MByte
Memory cards according to PCMCIA type I, II, and III.
External Keyboard PS/2 connector
