Applications The PACT Application
274 Agilent 8163A/B, 8164A/B & 8166A/B Mainframes, Sixth Edition
on zooming in and out.
• Press [Cancel] to return to the PACT Reference screen without completing
the stability application.
Figure 169 Low Dynamic Range
If you choose <High> or <Medium> as the [Dynamic] parameter and
<Continuous> sweep mode, the graph will update at the end of each
sweep. Figure 169 shows a graph with low dynamic range that is the
result of a single sweep. Figure 170 shows a graph with high dynamic
range that is the result of a three sweeps that were combined using a
"stitching" process.
NOTE
