Laser Safety Information Getting Started
Agilent 8163A/B, 8164A/B & 8166A/B Mainframes, Sixth Edition 31
Table 3 DFB Laser Source Modules - Laser Safety Information
Agilent 81662A Agilent 81663A
Laser Type CW DFB Laser
with built-in isolator
CW DFB Laser
with built-in isolator
Wavelength range 1500 - 1650 nm
see display
1500 - 1650 nm
see display
Max. CW output power
1
<15 mW <28 mW
Beam waist diameter 9 µm 9 µm
Numerical aperture 0.1 0.1
Laser Class according to
IEC 60825-1 (2001)- International
1M 1M
Max. permissible CW output power 163 mW 163 mW
1
Max. CW output power is defined as the highest possible optical power that the laser source can produce at its out
put connector.
