Agilent Technologies Agilent 8163A

Laser Safety Information Getting Started
Agilent 8163A/B, 8164A/B & 8166A/B Mainframes, Sixth Edition 33
Table 6 Compact Tunable Laser Modules - Laser Safety Information
Agilent 81980A Agilent 81940A Agilent 81944A Agilent 81989A Agilent 81949A
Laser Type ECL-Laser
InGaAsP
ECL-Laser
InGaAsP
ECL-Laser
InGaAsP
ECL-Laser
InGaAsP
ECL-Laser
InGaAsP
Wavelength range 1465 nm-1575 nm 1520 nm-1630 nm 1520 nm-1630 nm 1465 nm-1575 nm 1520 nm-1630 nm
Max. CW output power
1
20 mW 20 mW 20 mW 20 mW 20 mW
Beam waist diameter 9 µm 9 µm 9 µm 9 µm 9 µm
Numerical aperture 0.1 0.1 0.1 0.1 0.1
Laser Class according to
IEC 60825-1 (2001)- International
1M 1M 1M 1M 1M
Max. permissible CW output power 163 mW 163 mW 163 mW 163 mW 163 mW
1
Max. CW output power is defined as the highest possible optical power that the laser source can produce at its output connector.
Table 7 Compact Tunable Laser Modules (discontinued)- Laser Safety Information
Agilent 81689A Agilent 81689B Agilent 81649A
Laser Type FP-Laser
InGaAsP
FP-Laser
InGaAsP
FP-Laser
InGaAsP
Wavelength range 1400-1620 nm 1400-1620 nm 1400-1620 nm
Max. CW output power
1
<15 mW <15 mW <15 mW
Beam waist diameter 9 µm 9 µm 9 µm
Numerical aperture 0.1 0.1 0.1
Laser Class according to
IEC 60825-1 (2001)- International
1M 1M 1M
Max. permissible CW output power 163 mW 163 mW 163 mW
1
Max. CW output power is defined as the highest possible optical power that the laser source can produce at its output connector.
