Getting Started A Description of the User Interface
44 Agilent 8163A/B, 8164A/B & 8166A/B Mainframes, Sixth Edition
Figure 9 The Agilent 8164A/B’s Overview Screen
Figure 10 shows the overview screen for the Agilent 8166A Lightwave
Multichannel System, this screen is shown immediately after start-up. It
shows the module slots that are occupied.
Figure 10 The Agilent 8166A Overview Screen
