Chapter 4 Remote Interface Reference
SCPI Conformance Information
112
Device Specific Commands
The following commands are device-specific to the Agilent E3631A power supply.
They are not included in the 1995.0 version of the SCPI standard. However, these
commands are designed with the SCPI standard in mind and they follow all of the
command syntax rules defined by the standard.
Non-SCPI Commands
APPLy
{P6V|P25V|N25V}[,{<voltage>|DEF|MIN|MAX>}[,{<current>|DEF|MIN|MAX}]]
APPLy? [{P6V|P25V|N25}]
CALibration
:COUNt?
:CURRent[:DATA] <numeric value>
:CURRent:LEVel {MIN|MAX}
:SECure:CODE <new code>
:SECure:STATe {OFF|ON},<code>
:SECure:STATe?
:STRing <quoted string>
:STRing?
:VOLTage[:DATA] <numeric value>
:VOLTage:LEVel {MIN|MAX}
MEASure
:CURRent [:DC]? [{P6V|P25V|N25V}]
[:VOLTage][:DC]? [{P6V|P25V|N25V}]
OUTPUT
:TRACK[:STATe] {OFF|ON}
:TRACK[:STATe]?
SYSTem
:LOCal
:REMote
:RWLock
