Index
Index
firmware revision query 49
front panel
drawing 3
enabled / disable 48
key discription 4
voltage and current settings 5
front panel message 48
fuse rating 29
G
GPIB address 51
GPIB connector 55
GPIB interface 50
GPIB interface configuration 55
H
halting an output 109
I
idea constant-current supplies 145
ideal constant-voltage supplies 145
identifier 74
IEEE-488 common command 107
IEEE-488 conformance information 113
initial inspection 21
input power 24
installation 21
interface, GPIB 50
interface, RS-232 50
K
key
Calibrate 61
Display Limit 37
I/O Config 7
Local 37
On/Off 45
Secure 61
Track 42
key descriptions 4
keyword
root 104
second-level 104
third-level 104
knob locking 45
L
limit mode 19, 37
limit value 37
linear power supplies 143
load
active 151
capacitive loading 150
inductive loading 150
pulse loading 150
reverse current loading 151
locking knob control 45
loop stability 150
low-level command 72, 133
M
MAV bit 98
MAX parameter 106
measurement command 78
memory location 43, 86
messge
CAL MODE 61
meter mode 19, 37
meters 20
MIN parameter 106
multiple loads 149
N
noise
common mode current 147
normal mode voltage 147
non-SCPI command 112
O
operating range 152
options 18
output buffer 96, 99
output characteristics 145
output identifier 74
output impedance 145
output isolation 149
output name 74
output number 74
output on/off command 79
output selection command 76
output setting command 76
P
parameter
boolean 108
discrete 108
numeric 108
string 108
parity 51, 53, 56
performance specifications 158
power dissipation 155
power-line cord 24
power-line voltage selection 24
power-on / reset state 30, 33, 38, 40
preregulation 143
program 128
programming range 74
programming speed 153
down 154
up 153
protocol, DTR/DSR handshake 58
Q
query 73, 107
query command 73
query response 73
questionable status register 93
R
rack mounting 22
rack mounting kit
adapter kit 22
filler panel 23
flange kit 23
lock-link kit 23
shelf 23
slide kit 23
sliding support shelf 23
readback capabilities 19
rear panel
drawing 7
recall mode 44
recalling operating states 43
rectifier 143
register
questionable status 93
questionable status enable 94
questionable status event 94
standard event 95
standard event enable 96
status byte 96, 98
status byte enable 97
status byte summary 97
register, enable 90
register, event 90
reliability 155
remote interface configuration 50
reverse polarity diode 152
RS-232 interface 50
RS-232 interface commands 89
RS-232 interface configuration 56
