140 Agilent InfinityLab LC Series 1260 Infinity II Isocratic- and Quaternary Pumps User Manual
8
Maintenance
Remove and Install Doors
Remove and Install Doors
Parts required p/n Description
5067-5746 Door Assembly Infinity 180 Right
5067-5745 Door Assembly Infinity 180 Left
The figures shown in this procedure exemplarily show the Infinity II Multisampler module.
The principle of how to remove and/or install doors works in the same way for all Infinity
II modules.
1
Press the release buttons and pull the front door out.
2
For the Installation of the front door. Insert the hinges
into their guides and move the door in until the release
buttons click into their final position.
