240 Agilent InfinityLab LC Series 1260 Infinity II Isocratic- and Quaternary Pumps User Manual
12
LAN Configuration
Dynamic Host Configuration Protocol (DHCP)
Setup (DHCP)
The DHCP functionality is available on all Agilent HPLC modules with on-board LAN
Interface or LAN Interface Card G1369C, and “B”-firmware (B.06.40 or above) or modules
with "D"-firmware. All modules should use latest firmware from the same set.
1 Note the MAC address of the LAN interface (provided with G1369C LAN
Interface Card or Main Board). This MAC address is on a label on the card
or at the rear of the main board, e.g. 0030d3177321.
On the Local Controller the MAC address can be found under Details in the
LAN section.
Figure 28 LAN Setting on Instant Pilot
