Agilent InfinityLab LC Series 1260 Infinity II Isocratic- and Quaternary Pumps User Manual 155
Maintenance
8
Maintenance of a Pump Head Without Seal Wash Option
Maintenance of a Pump Head Without Seal Wash Option
When In case of maintenance or pump head internal leaks.
Tools required Description
Wrench 1/4 inch
Hexagonal key, 4 mm
Parts required # p/n Description
1 01018-23702 Insert tool
1 5063-6589 Piston seal PTFE, carbon filled, black (pack of 2), default
OR 1 0905-1420 PE seals (pack of 2)
1 5063-6586 Sapphire piston
1 8660-0852 Abrasive mesh
Preparations • Switch off the pump at the main power switch.
• Open the doors of the module.
• Remove the Pump Head Assembly.
1 Place the pump head on a flat surface. Loosen the lock
screw (two turns).
2 While holding the lower half of the assembly (piston
housing), carefully pull the pump housing away from the
piston housing.
