154 Agilent InfinityLab LC Series 1260 Infinity II Isocratic- and Quaternary Pumps User Manual
8
Maintenance
Remove the Pump Head Assembly
3
Using a 1/4 inch wrench disconnect the pump outlet
capillary from the purge valve. Disconnect the waste
tube.
Beware of leaking solvents due to hydrostatic
pressure.
4
If applicable, remove tubings from the seal wash support
rings.
5
Remove the capillary at the bottom of the pump head.
6
Using a 4 mm hexagonal key, stepwise loosen the two
pump head screws.
7
Remove the pump head from the pump drive.
To Next Page
