Agilent Technologies G7121B User Manual

222 Agilent InfinityLab LC Series 1260 Infinity II FLD User Manual
9 Maintenance
Replace Leak Handling System Parts
5
Pull the Leak Adapter from the Top Cover and remove it
together with the tubing.
Next Steps:
6 Install the Leak Adapter by pressing it into the Main
Cover.
7 Slide the Main Cover into its front position.
8 Press the main cover down at the rear until the levers
click.
9 Insert the Tubing [2] (ca. 85 mm required for
replacement) between Leak Adapter outlet and Leak
Pan.
10 Install the Doors, see “Remove and Install Doors” on
page 211.

