Instructions for Use
Storage, transport and handling
MS120 Single Stage Rotary Vane Pumps User Manual / 87-900-150-01(B) 139/198
Storage, transport and handling
Storage
The pumps must be stored or transported without oil.
When transporting and storing the pumps, the following
environmental requirements should not be exceeded:
temperature: from -20 °C to 70 °C
relative humidity: 0 – 95 % (non-condensing).
Lifting
The orientation of the packed components must correspond to the
instructions given by the pictograms on the external covering of the
packaging.
For unloading use a lifting equipment suitable for the pump weight.
For lifting the packaging and the pump, refer to the following figures.
Total weight of the pack, including the pump, is max. 120 kg. Weight
of the pump only is 106 kg.
Tab. 1 Packing size
Quota L B H
Dimension 920 mm 610 mm 790 mm
