User Interface
5
MS120 Single Stage Rotary Vane Pumps User Manual / 87-900-150-01(B) 191/198
WIN TYPE R/W DESCRIPTION
407 A R SW PARAMETER LISTING CODE & REVISION
503 N RW RS485 Address [0 - 31] It defines the RS485 serial communication address
504 L RW Serial communication standard [0 = RS232; 1 = RS485]
Pump Status
The Pump Status indicates the operating status of the pump.
The possible Status are the following:
 Stop = the pump is waiting for a START command
 Ramp = the pump has been started and is increasing the
rotational frequency in order to reach the target set point
 Normal Operation = the pump is running at the target frequency
 Fail = the pump is not running because has been detected an
error condition. The error condition can be discovered reading
the W206 value throug serial communication interface
 Autotuning = the pump rotational speed is not able to reach (or
maintain) the target value due to a too high gas load.
The Pump Status can be detected by looking at the STATUS LED or
reading the W205 value throug serial communication interface.
LED STATUS CONTROLLER STATUS
Green blinking
(once every 2 seconds)
Stop
Green blinking Ramp – Autotuning
Green Normal Operation
Red Fail
