Agilent Technologies MS120 User Manual

Technical Information
User Interface
5
MS120 Single Stage Rotary Vane Pumps User Manual / 87-900-150-01(B) 189/198
Command: STOP
Source: PC
Destination: Pump
02 80 30 30 30 31 30 03 42 32
STX ADDR WINDOW WR OFF ETX CRC
Source: Pump
Destination: PC
02 80 06
03 38 35
STX ADDR ACK ETX CRC
Command: READ PUMP STATUS
Source: PC
Destination: Pump (with address = 3)
02
83
32
30
35
30
03
38
37
STX
ADDR
WINDOW
RD
ETX
CRC
Source: Pump (with address = 3 in stop status)
Destination: PC
02
83
32
30
35
30
30
30
30
30
30
03
38
37
STX ADDR WINDOW DATA (STATUS) ETX CRC
Window Meanings
The following table describes the windows available to the user.
The columns R/W indicates if the window is read-only (R) or if it can
also be modified (RW).
The windows default values are shown in bold.
WIN TYPE R/W DESCRIPTION
000 L RW START/STOP (1= START; 0= STOP)
008 L RW REMOTE/SERIAL CONFIGURATION (1= Remote; 0= Serial)
102 N RW REMOTE I/O SET POINT VALUE [Hz] (0 – 127) 40
