Technical Information
MS120 Single Stage Rotary Vane Pumps User Manual / 87-900-150-01(B) 190/198
WIN TYPE R/W DESCRIPTION
105 N RW REMOTE I/O SET POINT HYSTERESIS [%] (0 – 100) 2
108 N RW SERIAL COMMUNICATION BAUD RATE (0-6)
[0=600, 1=1200, 2=2400, 3=4200, 4=9600, 5=19200 bit/s]
120 N RW ROTATIONAL FREQUENCY SETTING [Hz] (40 - 70) 50
201 N R 3PHASE VOLTAGE [V] 3phase Voltage supplied to the motor
202 N R POWER [W] Electrical power supplied to the motor
203 N R DRIVING FREQUENCY [Hz] Reads the actual electrical driving frequency
205 N R STATUS (0=Stop; 1=Wait interlock; 2=Start; 3=Autotuning; 5=Normal;
6=Fail)
206 N R ERROR CODE: [bit field]
Bit 7: Rotor locked
Bit 6: Short Circuit
Bit 5: Vline Under/Over Voltage
Bit 4: Motor Overtemp
Bit 3: Line Fault
Bit 2: Controller Overtemp
Bit 1: Vdc BUS Under Voltage
Bit 0: Over Current
211 N R CONTROLLLER POWER OUTPUT HEATSINK TEMPERATURE [°C]
216 N R CONTROLLER TEMPERATURE [°C] Controller inlet air temperature
222 N R CONTROLLLER POWER SUPPLY HEATSINK TEMPERATURE [°C]
234 N R BUS VOLTAGE [V] Controller internal DC BUS Voltage
235 N R LINE VOLTAGE [V
pk
] Supply line peak Voltage
300 N R CYCLE TIME [min] It indicates the time of the ongoing cycle (from the last
Start) or the time of the last cycle if the pump is in Stop status
301 N R CYCLE NUMBER Indicates the total number of Start/Stop cycles carried by
the pump
302 N R PUMP LIFE [h] Indicates the total hours of pump life in running condition
307 N R PUMP STAND-BY [h] Indicates the total hours of pump life in stand-by
(pump switched-on but not in running condition)
320 A R PUMP MODEL NUMBER
321 A R PUMP SPECIAL MODEL NUMBER
322 A R PUMP SERIAL NUMBER
406 A R SW PROGRAM LISTING CODE & REVISION
