Technical Information
Starting and Running the Pump
MS120 Single Stage Rotary Vane Pumps User Manual / 87-900-150-01(B) 176/198
Starting and Running the Pump
The pump can be operated in REMOTE mode through the Remote I/O
signals or in SERIAL mode through the RS232 or RS485 Serial
communication.
The defult configuration is REMOTE mode.
NOTE
To allow the pump starting you have to wire properly the START pins by
connecting the mating connector provided with the pump or by connecting pin 7
to pin 9 on J1 – I/O connector.
