Agilent Technologies MS120

Instructions for Use
Use
4
MS120 Single Stage Rotary Vane Pumps User Manual / 87-900-150-01(B) 152/198
Operating limits table
INPUT VOLTAGE (V)
CONTROLLER STATUS
< 180 Power fail (Undervoltage/Overvoltage Error –
Win205 bit5 = 1)
180 – 200
Operative (reduced performance)
200 – 264
Operative (full performance)
> 264 Power fail (Undervoltage/Overvoltage Error –
Win205 bit5 = 1)
Installation
Do not install or use the pump in an environment exposed to
atmospheric agents (rain, snow, ice), dust, aggressive gases, or in
explosive environments or those with a high fire risk.
During operation, the following environmental conditions must be
respected:
 temperature: from +12 °C to +35 °C
 relative humidity: 0 – 95% (non-condensing).
CAUTION!
Before starting the pump, fill up with lubricating oil as the pump is delivered
empty.
Further information for the oil refurbishment and the choice of the
suitable oil, refer to paragraph “Oil change”.
