Technical Information
MS120 Single Stage Rotary Vane Pumps User Manual / 87-900-150-01(B) 171/198
TECHNICAL DATA UNITS VALUE
Operating temperature range °C +12 to + 35
°F +54 to +95
Oil temperature range (pump operating) ** °C +62 to +90
°F +143 to +194
Inlet flange ISO KF DN40
ISO KF NW40
Outlet flange ISO KF DN25
ISO KF NW25
Main Dimensions:
- width mm 516
- length mm 750
- height mm 538
Oil capacity l 1,8
Gal US 0.47
Type lubricating fluid Inland 45
Total weight Kg 106
lbs 233
Oil temperature range
(pump operating) **
°C +62 to +90
°F +143 to +194
IP Value 20
Installation category II
Pollution degree 2
Max altitude m 2000
* According to PNEUROP standard 6602 ** At ultimate total pressure, 20 °C (68 °F) room temperature
#
Valid for temperatures up to 40°C and altitudes lower than 1000 m.
CE marks
EN61326-1 2013 Electrical equipment for measurement control and laboratory use EMC Requirements
Emission: EN55011 Class B; EN61000-3-2; EN61000-3-3
Immunity Industrial Levels:
EN61000-4-2 EN61000-4-8
