Agilent Technologies MS40-S User Manual

Technical Information
MS40-S User Manual 199
Technical specification
The following table lists the main technical data of the MS40-S Single Stage Rotary
Vane Pumps.
Table 8 Technical data
Technical data
RPM
UNITS
X3705-64000
Pumping speed (at 5 mbar inlet pressure)
1200
m
3
/h
40
Ultimate total pressure
*
mbar
5x10
-2
Oil capacity
l
1
Max noise level
dB(A)
≤62
IP grade
20
Installation category
II
Pollution degree
2
Operating temperature range
°C
12 – 40
Weight
kg
kg 34.5 (w/o oil)
lb
lb 76 (w/o oil)
Inlet flange
DN
25KF
Exhaust connection
mm
12
Main dimensions:
• length
mm
440
• width
mm
306
• height
mm
271
Nominal input voltage
Vac
200÷240
Input frequency
Hz
50÷60
Max input power
VA
3000
Indoor use only
Max altitude
m.a.s.l.
2000
**
According to ISO21360-1 e ISO21360-2
