Agilent Technologies MS40-S User Manual

Technical Information
214 MS40-S User Manual
Window Meanings
Table 16 Window meanings
WIN
TYPE
R/W
DESCRIPTION
000
N
R
START/STOP (1= START; 0= STOP)
008
N
R
REMOTE/SERIAL CONFIGURATION (1= Remote; 0= Serial)
1098
N
R
SERIAL BAUD RATE (0-5) [0=600, 1=1200, 2=2400, 3=4200, 4=9600,
5=19200 bit/s]
120
N
R
ROTATIONAL FREQUENCY SETTING [Hz] (40 - 60)
127
N
R
ROTATIONAL FREQUENCY SETTING [rpm] (read only)
202
N
R
ELECTRICAL POWER DELIVERED TO THE MOTOR [W]
203
N
R
ELECTRICAL DRIVING FREQUENCY [Hz]
205
N
R
PUMP STATUS
(0=stop; 1=wait interlock; 2=start; 3=autotuning; 5=normal; 6=fail)
206
N
R
ERROR CODE:
(Bit 7: Motor blocked; Bit 6: shortcircuit; Bit 5: Undervoltage/Overvoltage;
Bit 4: Motor overtemp; Bit 3: Verify line; Bit 2: Controller overtemp; Bit 1:
Bus Undervoltage; Bit 0: overcurrent)
216
N
R
CONTROLLER TEMPERATURE [°C]
223
N
R
PUMP BODY TEMPERATURE [°C]
233
N
R
ROTATIONAL FREQUENCY [rpm]
300
N
R
CYCLE TIME [min]
Time elapsed since start
301
N
R
CYCLE NUMBER
302
N
R
PUMP LIFE [h]
307
N
R
PUMP LIFE IN STAND BY (STOP STATUS) [h]
319
A
R
CONTROLLER MODEL NUMBER
320
A
R
PUMP MODEL NUMBER
321
A
R
PUMP SPECIAL MODEL NUMBER
322
A
R
PUMP SERIAL NUMBER
323
A
R
CONTROLLER SERIAL NUMBER
358
N
RW
MAINTENACE TIMER [hours]
362
N
R
LAST WORKING HOUR TEMPERATURE AVERAGE [°C]
