Agilent Technologies MS40-S

Technical Information
200 MS40-S User Manual
MS40-S outline
The following figures shows the pumps layout and dimensions:
Figure 23 MS40-S Single Stage Rotary Vane Pumps layout
Figure 24 MS40-S Single Stage Rotary Vane Pumps dimensions
Electronic controller
Electric motor
Pumping block
Inlet flange
Air filter
Oil level indicator
Exhaust
connection
