Specifications Appendix A
Series N6700 User’s Guide 127
Agilent N6700A/B MPS Mainframe
N6700A/B
Regulatory Compliance:
EMC
Safety
Complies with the European EMC directive 89/336/EEC for Class A test and measurement
products.
Complies with the Australian standard and carries the C-Tick mark.
This ISM device complies with Canadian ICES-001.
Cet appareil ISM est conforme à la norme NMB-001 du Canada.
Electrostatic discharges greater than 1 kV near the I/O connectors may cause the unit
to reset and require operator intervention.
Complies with the European Low Voltage Directive 73/23/EEC and carries the CE-marking.
This product also complies with the US and Canadian safety standards for test and
measurement products.
Acoustic Noise Declaration:
This statement is provided to comply with
the requirements of the German Sound
Emission Directive, from 18 January 1991.
Sound Pressure Lp <70 dB(A),
* At Operator Position, * Normal Operation, * According to EN 27779 (Type Test).
Schalldruckpegel Lp <70 dB(A)
* Am Arbeitsplatz, * Normaler Betrieb, * Nach EN 27779 (Typprüfung).
Output Terminal Isolation:
Maximum rating No output terminal may be more than 240 VDC from any other terminal or chassis ground.
AC Input:
Nominal Input Ratings
Input Range
Power Consumption
Fuse
100 VAC – 240 VAC; 50/60Hz/400Hz
86 VAC – 264 VAC
1000 VA typical (1100 VA maximum with power factor correction)
Internal fuse (not customer accessible)
Dimensions:
Height
Width
Depth
44.45 mm / 1.75 in.
432.5 mm / 17.03 in.
596.9 mm / 23.5 in.
Weight:
With 4 installed modules
Single power module
Net: 12.78 kg; 28 lbs.
Net: 1.23 kg; 2.71 lbs
Power Module Option Characteristics
Output Relays (Option 761): Output Lists (Option 054): Digitized Measurements (Option 054):
Type = Double-pole, double-throw
Location = output & sense terminals
Maximum number of steps = 512
Maximum dwell time in seconds = 262
Maximum list repetitions = 256, or infinite
Maximum measurement points = 4096
Maximum sample rate = 50 kHz
