Appendix E Compatibility
198 Series N6700 User’s Guide
Front Panel Menu Commands for Firmware Revisions prior to B.00.00
Menu Command Control Description
Output Voltage Programs voltage setting and range.
Current Programs current setting and range.
Delay Program Turn-on /Turn Off delay.
Measure Range Selects voltage and current measurement range.
Sweep Specifies measurement points, time interval, and trigger offset.
Window Selects measurement window (Rectangular/Hanning).
Control Lets you abort a measurement in progress.
Transient Mode Voltage Selects voltage mode (Fixed, Step, or List).
Current Selects current mode (Fixed, Step, or List).
Step Programs voltage and current steps. Enables step trigger signals.
List Pace Specifies Dwell or Trigger paced list.
Repeat Specifies number of list repetitions, or specifies continuous list.
Terminate Specifies list settings when the list terminates.
Config Configures the list steps. Specify voltage, current, and dwell values.
Also specifies trigger output signal states.
Reset Aborts the list and resets all list parameters.
TrigSource Specify the trigger source: bus, tran 1-4, pin 1-3.
Control Initiate, Trigger, or Abort output triggers.
Protect OVP Configures over-voltage protections function.
OCP Configures over-current protections function.
Inhibit Configures the external inhibit signal.
Coupling Disables ALL output channels when a protection fault occurs.
Clear Clears output protection.
States Reset Resets the instrument to its reset (*RST) state.
Save/Recall Saves or recalls an instrument state.
PowerOn Selects the power on state.
System Interface LAN Status Displays interface status information.
IP Enables/disables DHCP and Auto IP
Also sets the IP Address, Subnet Mask, and Default Gateway.
DNS Configures the DNS server.
Name Configures the Dynamic DNS and NetBIOS naming service.
Domain Configures the Domain Name.
TCP Configures the TCP keepalive function.
Enable Enables/disables the LAN interface and the built-in Web server.
USB Status Displays status, speed, packets received, and packets sent.
Identification USB connect string - the instrument’s unique USB identifier
Enable Enables/disables the USB interface.
GPIB Selects the GPIB address.
Reset Resets the interface settings to the factory-shipped state.
