Agilent Technologies N6751A User Manual

Compatibility Appendix E
Series N6700 User’s Guide 199
Menu Command Control Description
System DigPort Pin 1 Function Specifies the pin function: DigIO, TrigIn, TrigOut, DigIn, or FaultOut..
Polarity Specifies the pin polarity.
Pin 2 Function Specifies the pin function: DigIO, TrigIn, TrigOut, or DigIn.
Polarity Specifies the pin polarity.
Pin 3 Function Specifies the pin function: DigIO, TrigIn, TrigOut, DigIn, or InhibitIn.
Polarity Specifies the pin polarity.
Data Sends/reads data from the digital I/O port function
Preferences Display Configures Screen saver, Wake-on I/O, and Display contrast.
Keys Enables/disables key clicks and configures the On/Off key.
Security ResetNVRam Resets all non-volatile RAM settings to their factory defaults.
Error Displays the Error log.
Calibrate State Enables/disables calibration. You must supply a password to enable.
Sequence VProg High Enters measured data for high calibration point.
Low Enters measured data for low calibration point.
VMeas Enters measured data.
CMRR Calibrates common mode rejection ratio.
IProg High Enters measured data for high calibration point.
Low Enters measured data for low calibration point.
IMeas Enters Measured data.
DPRog Calibrates the downprogrammer.
IPeak Calibrates I peak.
Date Saves the calibration date for each channel.
Save Saves the calibration data.
Password Changes the password.
About Frame Displays model, serial number, firmware revision, backup revision,
and active firmware.
Module Displays model, serial number, options, voltage, current, and power.
