Language Dictionary 6
Series N6700 User’s Guide 77
SCPI Command Description
OUTPut (continued)
:PON
:STATe RST | RCL0 Programs the power-on state
:PROTection
:CLEar (@chanlist) Resets latched protection
:COUPle <Bool> Enables/disables channel coupling for protection faults
:DELay <NRf+>, (@chanlist) Sets over-current protection programming delay
SENSe
:CURRent [:DC]
:RANGe [:UPPer] <NRf+>, (@chanlist) Selects the current measurement range (Agilent N6761A/62A)
:FUNCtion “VOLTage” | ”CURRent”, (@chanlist) Selects the measurement function
:SWEep (Sweep commands only on Agilent N6761A/62A and Option 054)
:OFFSet:POINts <NRf+>, (@chanlist) Defines the trigger offset in the measurement sweep
:POINts <NRf+>, (@chanlist) Defines the number of data points in the measurement
:TINTerval <NRf+>, (@chanlist) Sets the measurement sample interval
:VOLTage [:DC]
:RANGe [:UPPer] <NRf+>, (@chanlist) Selects the voltage measurement range (Agilent N6761A/62A)
:WINDow [:TYPE] HANNing | RECTangular, (@chanlist) Selects the measurement window (N6761A/62A and Option 054)
[SOURce:]
CURRent
[:LEVel]
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist) Sets the output current
:TRIGgered [:AMPLitude] <NRf+>, (@chanlist) Sets the triggered output current
:MODE FIXed | STEP | LIST, (@chanlist) Sets the current trigger mode
:PROTection
:STATe <Bool>, (@chanlist) Enables/disables over-current protection on the selected output
:RANGe <NRf+>, (@chanlist) Sets the output current range (Agilent N6761A/62A)
DIGital
:INPut:DATA? Reads the state of the digital port pins
:OUTPut:DATA <NRf> Sets the digital port
:PIN1 | :PIN2 | :PIN3 | :PIN4 | :PIN5 | :PIN6 | :PIN7
:FUNCtion DIO | DINP | TOUT | TINP | FAUL
1
| INH
2
Sets the selected pin’s function (
1
PIN1 only;
2
PIN3 only)
:POLarity POSitive | NEGative Sets the selected pin’s polarity
LIST (List commands only on Agilent N6761A/62A and Option 054)
:COUNt <NRf+> | INFinity, (@chanlist) Sets the list repeat count
:CURRent [:LEVel] <NRf> {,<NRf>}, (@chanlist) Sets the current list
:POINts? (@chanlist) Returns the number of current list points
:DWELl <NRf> {,<NRf>}, (@chanlist) Sets the list of dwell times
:POINts? (@chanlist) Returns the number of dwell list points
:STEP ONCE | AUTO, (@chanlist) Specifies how the list responds to triggers
:TERMinate
:LAST <Bool>, (@chanlist) Sets the list termination mode
:TOUTput
:BOSTep[:DATA] <Bool> {,<Bool>}, (@chanlist) Sets the steps to generate triggers at the Begin Of Step
:POINts? (@chanlist) Returns the number of beginning of step list points
:EOSTep[:DATA] <Bool> {,<Bool>}, (@chanlist) Sets the steps to generate triggers at the End Of Step
:POINts? (@chanlist) Returns the number of end of step list points
:VOLTage[:LEVel] <NRf> {,<NRf>}, (@chanlist) Sets the voltage list
:POINts? (@chanlist) Returns the number of voltage level points
STEP
:TOUTput <Bool>, (@chanlist) Generate a trigger output on the voltage or current step transient
